详细参数
| 技术参数 Specifications | ||||||||||||
| Voltage | Frequency | Current | Input Power | Speed | Capacitor | Air Flow |
Noise | Temperature | Curve No. | Approvals | ||
| Type | v | Hz | A | W | RPM | uF | m³/h / CFM | dB(A) | Min / Max (℃) | # | ||
| A2E145S-5AN-AA10 | 220/230 | 50 | 0.2 | 40 | 2850 | 1.5 | 260 / 153 | 46 | -30/+60 | ① | CCC.CE,RoHS | |
| 60 | 0.2 | 45 | 3200 | 300 / 177 | 49 | ② | ||||||
| A2D145S-5AN-AA10 | 380/400 | 50 | 0.15 | 50 | 2800 | / | 260 / 153 | 46 | -30/+60 | ① | CCC,CE,RoHS | |
| 60 | 0.1 | 35 | 3200 | 300 /177 | 49 | ② | ||||||
| 曲线 Curves | |||||||
 |
|||||||
|
