Φ185 AC轴流风机
产品概述
风轮材质: 冷轧钢板 Material: Sheet aluminium
防护等级: IP54 Protection Class: IP54
认证: CCC CE Approvals: CCC CE
绝缘等级: F级 Insulation class: F
详细参数
| 技术参数 Specifications | ||||||||||||
| Voltage | Frequency | Current | Input Power | Speed | Capacitor | Air Flow | Noise | Temperature | Curve No. | Approvals | ||
| Type | V | Hz | A | W | RPM | uF | m³/h / CFM | dB(A) | Min / Max (℃) | # | ||
| A2D185S-5AN-AA1Y | 380/400 | 50 | 0.09 | 35 | 2600 | / | 660/ 388 | 65 | -30/+60 | ① | CCC.CE,RoHS | |
| 60 | 0.08 | 50 | 2900 | 740 / 435 | 65 | ② | ||||||
| 曲线 Curves | |||||||
 |
|||||||
|
